The Rigol DS1102Z-E is a compact yet powerful 100MHz digital oscilloscope designed for engineers, technicians, and educators who require reliable signal measurement and analysis. Equipped with 2 analog channels and a real-time sampling rate of up to 1 GSa/s, this oscilloscope delivers the performance needed for a wide range of electronic test and measurement tasks.

Part of Rigol’s acclaimed DS1000Z series, the DS1102Z-E combines deep memory, intuitive user controls, and advanced analysis tools, making it ideal for troubleshooting, design verification, and educational use. The built-in 24 Mpts memory depth allows users to capture long-duration signals without sacrificing resolution, while the 7-inch WVGA display ensures clear waveform visualization.

Whether you're working in a lab, on a production line, or in a classroom, the Rigol DS1102Z-E offers professional-level capabilities in a cost-effective, user-friendly package.

Key Features:

• 100MHz analog bandwidth

• 2 analog input channels

• Real-time sampling rate of up to 1 GSa/s

• 24 Mpts memory depth per channel

• Up to 30,000 wfms/s waveform capture rate

• Advanced triggering modes (edge, pulse, video, slope, alternate)

• Large 7” WVGA (800x480) color display

• USB host and device connectivity for data transfer and remote control

• Compact and lightweight bench-top design

• Compatible with optional serial decoding and signal analysis software

Technical Specifications:

• Bandwidth: 100 MHz

• Channels: 2 analog

• Sampling Rate: 1 GSa/s (real-time)

• Memory Depth: 24 million points

• Waveform Capture Rate: Up to 30,000 wfms/s

• Vertical Resolution: 8-bit

• Time Base Range: 5 ns/div to 50 s/div

• Vertical Sensitivity: 1 mV/div to 10 V/div

• Trigger Modes: Edge, Pulse Width, Video, Slope, Alternate

• Display: 7” WVGA TFT-LCD, 800 × 480 resolution

• Connectivity: USB Host, USB Device, LAN (via USB adapter)

• Input Impedance: 1 MΩ ±2%

• Weight: Approx. 2.5 kg

• Power Supply: 100–240 V AC, 45–440 Hz

Applications:

• Educational Laboratories – Ideal for electronics courses, lab training, and student experimentation

• Embedded System Debugging – Analyze mixed-signal behavior in microcontroller and FPGA-based systems

• Service & Repair – Diagnose and troubleshoot electronic circuits in repair centers and maintenance shops

• Design Verification – Validate prototypes and evaluate waveforms in product development cycles

• Signal Integrity Testing – Capture transient events and validate analog/digital signal performance

• General R&D – Use in research environments for low- to mid-frequency waveform observation

• Industrial Testing – Monitor electronic components and assemblies in manufacturing workflows
