The Rigol DG1032Z is a high-precision 30MHz dual-channel arbitrary waveform generator designed for advanced electronics testing, R&D, and academic environments. With support for multiple waveform types, precise frequency control, and dual synchronized outputs, it offers the flexibility and accuracy needed for complex signal simulations and functional tests.

Engineered for performance and reliability, the DG1032Z delivers high signal fidelity, low jitter, and advanced modulation capabilities including AM, FM, PM, FSK, and PWM. The large TFT color display and intuitive user interface simplify waveform editing and configuration, while the integrated USB and LAN connectivity enable remote operation and PC-based control.

Ideal for circuit development, embedded system validation, and signal integrity testing, the Rigol DG1032Z combines affordability with professional-grade performance.

Key Features

• 30MHz bandwidth with dual independent output channels

• Supports sine, square, ramp, pulse, noise, and arbitrary waveforms

• Built-in modulation functions: AM, FM, PM, PWM, FSK

• 250MSa/s sampling rate and 14-bit vertical resolution

• 1Mpts memory depth for long and complex waveforms

• USB host/device and LAN interfaces for connectivity and remote control

• Large 3.5" color LCD display with intuitive menu navigation

• Built-in waveform editing software for creating custom signal profiles

Applications

• Functional and performance testing of analog and digital circuits

• Development and validation of embedded systems

• Educational use in university and technical labs

• Signal simulation for communication system prototyping

• Waveform generation in audio, RF, and mixed-signal applications

Technical Specifications

• Model: Rigol DG1032Z

• Channels: 2 independent outputs

• Frequency Range: Up to 30MHz

• Sample Rate: 250MSa/s

• Vertical Resolution: 14-bit

• Memory Depth: 1Mpts

• Waveforms: Sine, Square, Ramp, Pulse, Noise, Arbitrary

• Modulation Types: AM, FM, PM, PWM, FSK

• Interfaces: USB Host/Device, LAN (LXI compliant)

• Display: 3.5-inch TFT color LCD

• Form Factor: Compact benchtop design

• Weight: Approx. 3.6kg
