Rigol DS1104Z-Plus 100MHz 4-Channel Digital Oscilloscope – 1GSa/s Sampling Rate with Deep Memory & Built-in Waveform Generator
Official Store
৳78,800.00
/pc
Inclusive of all taxes
Best Price Guarantee
Delivery in 15 Days
100% Authentic
Genuine Brand Guarantee
Cash on Delivery
Pay When You Receive
7-Day Warranty
Hassle-Free Replacement
1
TIG Welding Tungsten Electrode 2.4mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#2
TIG Welding Tungsten Electrode 1.6mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#3
Solder Crystal Rosin Flux BK-220 by BAKU – Clean Soldering, Smooth Connections
#4
Bambu Lab PLA Matte Ivory White Filament 1.75mm – Premium 3D Printing Material for Smooth, Precise Prints
#5
Beelayers Pla+ Black 3D Printer Filament 1.75mm
#6
Beelayers PLA+ White 3D Printer Filament 1.75mm – High Strength PLA Plus Filament for FDM 3D Printing
The Rigol DS1104Z-Plus is a high-performance 100MHz digital storage oscilloscope designed to meet the demanding needs of engineers, technicians, and educators. Featuring four fully isolated analog channels, a real-time sampling rate of up to 1 GSa/s, and an impressive 24 Mpts memory depth (upgradeable to 112 Mpts), this scope is built for advanced signal analysis and accurate waveform capture.
As part of Rigol’s trusted Z-series, the DS1104Z-Plus delivers industry-leading value with a rich set of functions such as serial bus decoding, advanced trigger modes, and built-in waveform recording. Whether you're troubleshooting embedded systems, analyzing analog/digital circuits, or conducting lab research, this oscilloscope provides the power, clarity, and flexibility professionals require.
Key Performance Features:
-
100MHz Bandwidth across 4 Analog Channels – Capture multiple high-speed signals with precision
-
1 GSa/s Real-Time Sampling Rate – Accurately measure transient waveforms and glitches
-
24 Mpts Standard Memory Depth – Allows long-duration waveform recording with full resolution
-
Built-in 2-Channel 25 MHz Waveform Generator – Ideal for signal simulation and testing
-
Up to 30,000 wfms/s Waveform Capture Rate – Detect and visualize rare events or timing anomalies
-
Serial Bus Decoding – Supports I2C, SPI, UART, CAN, and more for embedded system debugging
-
Advanced Triggering – Includes edge, pulse width, slope, video, pattern, and more
-
7-inch WVGA Display (800×480) – Large, high-contrast screen for waveform clarity
-
USB Host & Device Ports, LAN Connectivity – Flexible data saving, remote control, and updates
-
Compatible with UltraScope PC Software – Enhanced data visualization and reporting
Technical Specifications:
| Specification | Details |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 4 Analog Channels |
| Real-Time Sample Rate | 1 GSa/s |
| Memory Depth | 24 Mpts (Standard), 112 Mpts (Opt.) |
| Waveform Capture Rate | Up to 30,000 wfms/s |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Trigger Types | Edge, Pulse, Slope, Video, Pattern |
| Serial Protocol Decoding | I2C, SPI, UART/RS232, CAN, LIN |
| Display | 7" WVGA TFT LCD (800×480) |
| Built-in Generator | 2-Channel, 25 MHz Arbitrary Generator |
| Interfaces | USB Host, USB Device, LAN |
| Form Factor | Bench-Top Compact Design |
| Power Supply | 100–240 V AC, 50/60 Hz |
Ideal Applications:
-
Embedded systems diagnostics
-
Analog and digital circuit development
-
Serial communication debugging
-
Research and academic laboratories
-
Industrial automation testing
-
Mixed-signal design analysis
Why Choose the Rigol DS1104Z-Plus?
The Rigol DS1104Z-Plus delivers a powerful feature set at an accessible price point. With four high-speed channels, deep memory, fast waveform capture, and optional advanced analysis tools, it’s engineered for serious electronics professionals. Whether you're a field engineer, educator, or lab technician, this oscilloscope combines performance, expandability, and reliability to support complex testing needs.
| Specification | Details |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 4 Analog Channels |
| Real-Time Sample Rate | 1 GSa/s |
| Memory Depth | 24 Mpts (Standard), 112 Mpts (Opt.) |
| Waveform Capture Rate | Up to 30,000 wfms/s |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Trigger Types | Edge, Pulse, Slope, Video, Pattern |
| Serial Protocol Decoding | I2C, SPI, UART/RS232, CAN, LIN |
| Display | 7" WVGA TFT LCD (800×480) |
| Built-in Generator | 2-Channel, 25 MHz Arbitrary Generator |
| Interfaces | USB Host, USB Device, LAN |
| Form Factor | Bench-Top Compact Design |
| Power Supply | 100–240 V AC, 50/60 Hz |
