FNIRSI 1013D Tablet Dual Channel Digital Oscilloscope – 100MHz Bandwidth, 1GS/s Sampling Rate, Touchscreen Portable Waveform Analyzer for Electronics & Circuit Testing
Official Store
৳21,580.00
৳21,890.00
-1% OFF
/pc
Inclusive of all taxes
Best Price Guarantee
Delivery in 7 Days
100% Authentic
Genuine Brand Guarantee
Cash on Delivery
Pay When You Receive
7-Day Warranty
Hassle-Free Replacement
1
TIG Welding Tungsten Electrode 2.4mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#2
TIG Welding Tungsten Electrode 1.6mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#3
Solder Crystal Rosin Flux BK-220 by BAKU – Clean Soldering, Smooth Connections
#4
Bambu Lab PLA Matte Ivory White Filament 1.75mm – Premium 3D Printing Material for Smooth, Precise Prints
#5
Beelayers Pla+ Black 3D Printer Filament 1.75mm
#6
Beelayers PLA+ White 3D Printer Filament 1.75mm – High Strength PLA Plus Filament for FDM 3D Printing
FNIRSI 1013D Tablet Dual Channel Digital Oscilloscope – Advanced 100MHz Touchscreen Waveform Analyzer with 1GS/s Sampling Rate for Precision Electronics & Circuit Diagnostics
The FNIRSI 1013D Tablet Dual Channel Digital Oscilloscope is a next-generation portable diagnostic tool, engineered for professionals, researchers, and electronics enthusiasts who demand ultra-precise waveform analysis, high-speed signal capture, and modern touchscreen control. With a true 100MHz bandwidth and an ultra-fast 1GS/s real-time sampling rate, this oscilloscope delivers exceptional accuracy in capturing, displaying, and analyzing even the fastest transient signals in both analog and digital circuits.
High-Performance Dual Channel Analysis
Equipped with two independent input channels, the FNIRSI 1013D allows simultaneous monitoring of multiple signal sources. This dual-channel capability is perfect for comparative measurements, signal synchronization testing, and troubleshooting complex circuits where analyzing multiple points at once is critical.
Advanced Touchscreen Interface
The large, high-resolution capacitive touchscreen transforms your testing workflow into a seamless experience. You can zoom, pan, measure, and adjust trigger settings effortlessly — just like using a tablet. The intuitive graphical user interface (GUI) reduces setup time and increases productivity, making it a perfect choice for both beginners and seasoned engineers.
Precision Measurements with Powerful Functions
The FNIRSI 1013D offers an extensive set of features, including:
-
Multiple Trigger Modes (Edge, Pulse, Video, Slope) for capturing specific signal events
-
Automatic Measurements such as frequency, duty cycle, peak-to-peak voltage, RMS, and more
-
Waveform Storage & Recall for post-analysis and documentation
-
Built-in Math Functions (Addition, Subtraction, FFT Spectrum Analysis) for advanced signal processing
Portable & Field-Ready Design
Built with a slim, lightweight tablet form factor and integrated rechargeable lithium battery, the FNIRSI 1013D is designed for portability without sacrificing performance. Ideal for on-site troubleshooting, automotive diagnostics, industrial electronics maintenance, embedded system debugging, and academic research, it provides reliable operation even in challenging field conditions.
Technical Specifications:
-
Bandwidth: 100MHz
-
Sampling Rate: 1GS/s real-time
-
Channels: 2 Independent
-
Display: Large Capacitive Touchscreen (High Resolution)
-
Vertical Sensitivity: 10mV/div to 10V/div
-
Time Base Range: 10ns/div to 1s/div
-
Trigger Modes: Edge, Pulse, Video, Slope
-
Battery: Rechargeable Lithium-ion (Long Life)
-
Connectivity: USB Interface for Data Transfer & Firmware Updates
-
Waveform Storage: Save & recall for later analysis
Technical Specifications
Official specifications for FNIRSI 1013D Tablet Dual Channel Digital Oscilloscope – 100MHz Bandwidth, 1GS/s Sampling Rate, Touchscreen Portable Waveform Analyzer for Electronics & Circuit Testing.
| Specification | Details |
|---|---|
| Product Name | FNIRSI 1013D Tablet Dual Channel Digital Oscilloscope – 100MHz Bandwidth, 1GS/s Sampling Rate, Touchscreen Portable Waveform Analyzer for Electronics & Circuit Testing |
| Brand / Manufacturer | Fnirsi |
| Category | Digital Oscilloscope |
| Unit | pc |
| Power Compatibility | 220V AC, 50Hz (Standard Bangladesh Grid Compatible) |
| Warranty & Service | Official Warranty & Technical Support at Industrial 3D Solution, Dhaka |
| Delivery Coverage | Fast Delivery inside Dhaka & Nationwide Courier to all 64 Districts |
