Vertical Winding Machine

Official Store
Quote Required Institutional / Custom Order

Price is customized based on project specifications, quantity, and requirements. Click below for an official quotation.

Instant RFQ Submission Official VAT / Commercial Invoice Fast Response within 2-4 Hours
Request for Quotation
Fast Delivery

Dhaka 24-48h, Nationwide 2-3 Days

100% Authentic

Genuine Brand Guarantee

Cash on Delivery

Pay When You Receive

7-Day Warranty

Hassle-Free Replacement



The vertical winding machine is a precision-engineered solution designed for the coil winding of medium and high-voltage power transformers. Ideal for manufacturing distribution and power transformer windings, this machine is optimized for space efficiency, vertical coil building, and controlled tensioning of conductor materials.

Built with a robust mechanical frame and integrated with advanced automation controls, the vertical winding machine supports copper and aluminum conductors in strip or wire form. It enables precise layering, tension control, and axial alignment to ensure the structural integrity and electrical performance of transformer coils.

With a modular design and user-friendly interface, this machine can be tailored for various coil sizes, conductor profiles, and insulation types. It is an essential part of transformer manufacturing lines focused on quality, repeatability, and production efficiency.

 Features:

  • Suitable for high-voltage and distribution transformer coil winding

  • Supports copper and aluminum conductors in strip or round wire form

  • Vertical coil build-up for space-saving operation and easy handling

  • Precision tension control system for uniform winding

  • PLC or HMI-based operation with programmable settings

  • Sturdy base frame with high load capacity and vibration control

  • Available with automatic taping, de-reeling, and insulation feeders

  • Optional servo motor drives for enhanced positioning accuracy

Applications:

  • Power transformer manufacturing

  • Distribution transformer coil winding

  • Medium and high-voltage coil production

  • Electrical equipment fabrication

  • Industrial transformer workshops

Technical Specifications:

Specification Details
Winding Type Vertical axis winding
Conductor Type Copper or aluminum (round wire or strip)
Coil Diameter Range Up to 2500 mm (customizable)
Coil Height Up to 3000 mm (customizable)
Drive System AC/Servo motor with variable speed control
Tension Control Pneumatic, mechanical, or servo-based
Automation PLC or HMI-based programmable controls
Load Capacity Up to 5 tons (varies by model)
Optional Features Automatic taping, insulation feeder, remote diagnostics
Standards Compliance CE, ISO 9001, transformer manufacturing standards
