HEDS-9730 180 LPI Encoder Strip – 400mm

The HEDS-9730 180 LPI Encoder Strip is a high-precision optical linear encoder designed to provide accurate position feedback in a variety of applications, including motion control, automation systems, and robotics. This incremental encoder strip, paired with a compatible encoder module, is widely used in devices that require precise measurement of linear movement or position.

Key Features:

• 180 LPI (Lines Per Inch) Resolution: Provides high-resolution optical feedback for precise tracking of linear motion. The encoder strip offers exceptional detail with each line of the code, ensuring accurate detection.

• 400mm Strip Length: The 400mm length ensures a wide detection area, making it suitable for larger applications that require extended range motion sensing.

• High-Quality Optical Design: The strip is made from durable, optically clear materials, ensuring minimal signal interference and high reliability in various conditions.

• Compatible with HEDS-9730 and HEDS-9731 Modules: Designed to integrate seamlessly with HEDS-9730 or HEDS-9731 encoder modules, the strip provides accurate incremental feedback on position, speed, and direction.

• Durable and Reliable Performance: Built to withstand demanding environments, the encoder strip maintains consistent performance in industrial settings, providing long-lasting and accurate operation.

• Two-Channel Quadrature Output: Delivers two-channel quadrature output, which is essential for determining the direction of motion and calculating speed.

Applications:

The HEDS-9730 Encoder Strip is ideal for any application that requires precise linear motion tracking or position feedback. Some of the common use cases include:

• CNC Machines: For precise control of cutting tools, positioning, and automation.

• 3D Printers: To provide accurate motion feedback for precise printing.

• Industrial Automation: Used in various machines that require accurate positioning of components in processes like assembly lines or packaging.

• Robotics: Helps in feedback for robotic arms or automated assembly lines.

• Printers and Plotters: Provides accurate position feedback for large-format printing equipment.

• Linear Actuators: Used in systems where precise motion control is required for positioning.

Technical Specifications:

• Resolution: 180 lines per inch (LPI)

• Strip Length: 400mm

• Output Type: Two-channel quadrature

• Material: Durable optically clear material

• Compatibility: Designed for use with HEDS-9730 and HEDS-9731 encoder modules

• Operating Temperature: Suitable for industrial environments with a wide operating temperature range.

Why Choose the HEDS-9730 180 LPI Encoder Strip?

The HEDS-9730 Encoder Strip provides a reliable and precise solution for motion feedback and position tracking. Whether you're upgrading existing equipment or designing new systems, this encoder strip ensures accuracy, durability, and ease of integration. Its high resolution and compatibility with industry-standard encoder modules make it a top choice for professionals in automation, robotics, CNC machining, and other precision applications.
