Hantek 2D72 Digital Oscilloscope – 70MHz 2 Channels | 3-in-1 Handheld Oscilloscope, Multimeter & Waveform Generator

The Hantek 2D72 is a compact, high-precision 3-in-1 handheld device that functions as a digital oscilloscope, waveform generator, and true RMS multimeter. Engineered for versatility, performance, and portability, it’s the ideal tool for engineers, technicians, students, and electronics hobbyists who need a reliable and multifunctional instrument in the lab or on the go.

✅ Product Overview:

The oscilloscope function features 2 analog channels, a bandwidth of 70MHz, and a maximum real-time sampling rate of 250MSa/s, allowing you to capture fast and complex waveforms with high accuracy. The waveform generator supports a wide range of standard signals (including sine, square, triangle, ramp, pulse, and arbitrary waveforms), making it perfect for signal simulation and circuit testing. Meanwhile, the digital multimeter provides all the essential measurement functions—voltage, current, resistance, capacitance, diode testing, continuity, and more.

All this is packed into a portable handheld unit, complete with a 2.8-inch TFT color LCD screen for clear waveform visualization and data reading. The durable design, intuitive interface, long battery life, and USB support make this scope a true all-in-one diagnostic and development tool.

? Detailed Features:

? Oscilloscope Functionality:

• Channels: 2 analog input channels

• Bandwidth: 70MHz

• Sampling Rate: Up to 250MSa/s

• Memory Depth: 6K per channel

• Input Impedance: 1MΩ ± 2%, 20pF ± 3pF

• Time Base Range: 5ns/div ~ 50s/div

• Vertical Sensitivity: 10mV/div ~ 5V/div

• Trigger Modes: Auto, Normal, Single

• Trigger Types: Edge, Pulse, Video, Slope

? Waveform Generator:

• Output Waveforms: Sine, Square, Triangle, Ramp, Pulse, Arbitrary

• Frequency Range: 1Hz to 25MHz

• Amplitude: 0.1V – 3.3Vpp adjustable

• Output Impedance: 50Ω

• Ideal for testing amplifiers, filters, and sensors

? Digital Multimeter:

• Voltage Measurement: DC up to 1000V, AC up to 750V

• Current Measurement: DC/AC up to 10A

• Resistance: Up to 60MΩ

• Capacitance: Up to 100mF

• Frequency Measurement: Up to 60MHz

• Diode Test, Continuity Beeper

• Auto and Manual Ranging Options

• True RMS measurement for AC signals

? Power & Portability:

• Battery: Built-in 3.7V 5000mAh rechargeable lithium battery

• Battery Life: Up to 6 hours of continuous operation

• Charging Interface: Micro USB

• Weight: Approximately 500g

• Size: 190mm x 95mm x 40mm

• Rugged build for field use and portability

? What's in the Box:

• Hantek 2D72 Oscilloscope Unit

• 2x Passive Oscilloscope Probes (1x/10x switchable)

• 1x Pair of Multimeter Test Leads

• USB Charging/Data Cable

• Power Adapter

• English User Manual

• Protective Carrying Case

? Use Cases & Applications:

• Circuit design and debugging

• Signal tracing and waveform analysis

• Automotive electronic diagnostics

• Educational laboratory equipment

• Industrial equipment maintenance

• Embedded system development

• Audio equipment testing

• Hobbyist and DIY electronics projects

? Why Choose the Hantek 2D72?

• Save space and money with a 3-in-1 device

• Get professional-grade measurements in a handheld format

• Simplify your toolkit without compromising on accuracy

• Great for both beginners and professionals

• Trusted Hantek quality and reliability
