Hantek DSO4254B Digital Storage Oscilloscope – 4 Channels, 250MHz, 1GS/s Sample Rate, LCD, PC Integrated, USB Portable

The Hantek DSO4254B is a high-performance 4-channel digital storage oscilloscope (DSO) designed for professionals, engineers, and researchers who require accurate signal analysis and waveform visualization. With a 250MHz bandwidth, 1GS/s real-time sampling rate, and deep memory storage, this oscilloscope delivers precise and reliable performance for a variety of applications, including circuit design, debugging, and troubleshooting. Its PC integration and USB connectivity provide seamless data transfer and analysis, making it a versatile and portable tool for both lab and field use.

Key Features & Specifications

? High Bandwidth & Fast Sampling Rate

• 250MHz bandwidth ensures accurate signal measurement across a wide frequency range.
• 1GS/s real-time sampling rate captures fast-changing waveforms with high precision.

? 4-Channel Input for Multi-Signal Analysis

• Allows simultaneous measurement of four independent signals, improving efficiency in debugging complex circuits.

? Large LCD Display (800×480 Resolution)

• High-resolution color screen provides a clear and detailed view of waveforms for easy analysis.

? Deep Memory Storage (64Mpts)

• Extended recording capability enables detailed signal examination over long periods.

? Advanced Triggering System

• Supports Edge, Pulse, Video, Slope, and Alternative triggering, allowing precise signal capture.

? Powerful Math & Measurement Functions

• Includes FFT analysis, addition, subtraction, multiplication, division, and waveform comparison for in-depth signal processing.

? PC Integration & USB Connectivity

• Easily connects to a computer via USB, allowing waveform storage, analysis, and report generation.

? Portable & Durable Design

• Compact and lightweight, making it suitable for both laboratory and field applications.

Ideal Applications

✅ Electronics circuit design & testing
✅ Power supply analysis & troubleshooting
✅ Embedded system development
✅ Automotive diagnostics
✅ Communication system testing
✅ Research & educational labs

The Hantek DSO4254B is a powerful, user-friendly, and cost-effective digital storage oscilloscope, making it an essential tool for engineers, researchers, and technicians. With 4-channel functionality, high-speed sampling, and deep memory storage, it offers professional-grade performance for accurate waveform analysis and troubleshooting.
