Input voltage range 7-70.00V Output voltage range 0-60.000V Output current range 0-12.000A/0-6.0000A Output power range 0-720.00W Output voltage accuracy between setting and measurement ±(0.5‰+4 digits) Output current accuracy between setting and measurement ±(1‰+6 digits) Automatic cut off current value when charging Set by yourself Output ripple typical 20mV VPP① Working temperature range -10℃~40℃ Max output voltage （input voltage÷1.1）-2② ①:Ripple measurement method: noise and ripple are measured at X1 range, AC coupling, 20 MHz of bandwidth on your oscilloscope with a 0.1uF parallel capacitor at the output terminals ②for example: input voltage is 24V，the max output voltage is 19.8V.

• 1.5-digit display,support 12A/6A current range switch, you can get 0.0001A resolution at 6A range,0.001A resolution at 12A range
• 2.RD6012P series has two versions:RD6012P and RD6012P-W,RD6012P-W have WIFI board , RD6012P don't have . RD6012P-W can use WIFI board to connect APP, also use USB micro cable to connect PC solftware . RD6012P don't have WIFI board, only support PC software by connecting with USB micro cable, no support APP. For wifi board to connect PC software, now it did not support.
• 3.The App Supports Android 5.0 to Android 10.0 , IOS10.0-13.4 mobile phone operating system, Win7-Win10 PC system, there may be incompatibilities problems, please download first before buying , if you can run it on your phone, you can make order, if not, please stop buying
• 4.There is a backup fuse in the box, if you burn the fuse, you can insert the fuse in the socket next to the burned one for short time use, and it can only support under 10A usage, but for better experience(12A output), please replace the burnt fuse
• 5.User Friendly interface, keypad control, DIY display style, APP control, PC software, for more function, please check the instruction
