Product Overview

The Dial Gauge Magnetic Holder Stand is a high-stability precision measuring accessory engineered for CNC machining, tool alignment, metrology, and industrial inspection tasks. Built with a powerful magnetic base, rigid articulated arms, and fine-adjustment locking joints, this stand delivers zero drift, vibration resistance, and repeatable accuracy even in demanding workshop environments.

Designed to securely hold dial gauges, dial indicators, and test indicators, this magnetic stand is an essential tool for precision measurement, quality control, and machine setup across manufacturing, automotive, mold making, and fabrication industries.

This model targets professionals who require reliable magnetic clamping force, smooth micro-adjustment, and long-term durability for accurate dimensional inspection.

Key Features

Powerful Magnetic Base

Equipped with a high-strength permanent magnet, the base provides instant, firm attachment to machine tables, lathes, milling machines, surface plates, and steel structures. The on/off magnetic switch ensures safe positioning and easy relocation without surface damage.

Precision Fine Adjustment Mechanism

The built-in fine adjustment screw allows micro-level positioning of the dial indicator, enabling high-resolution readings and precise alignment during inspection or setup.

Rigid Articulated Arm Design

Multiple locking joints with hardened clamping points ensure maximum rigidity, preventing indicator movement during measurement. Once locked, the structure remains rock-solid under vibration.

Universal Dial Indicator Compatibility

Supports 8mm and 3/8″ stem dial indicators, making it compatible with most standard dial gauges, test indicators, and precision measurement probes.

Industrial-Grade Construction

Manufactured from hardened steel and corrosion-resistant components, this magnetic holder stand is built for long service life in harsh workshop environments.

Technical Specifications

• Base Type: Permanent magnetic base with ON/OFF switch

• Magnetic Holding Force: High holding strength for industrial applications

• Arm Type: Multi-joint articulated arm with locking knobs

• Fine Adjustment: Yes (precision micro adjustment)

• Stem Compatibility: 8mm / 3⁄8 inch dial indicator stems

• Mounting Surface: Steel, cast iron, machine tables

• Material: Hardened steel body with anti-corrosion finish

• Application Type: CNC machining, metrology, inspection, alignment

Applications

• CNC machining and setup alignment

• Lathe, milling, and grinding machine inspection

• Dial indicator measurement and runout checking

• Surface flatness and parallelism testing

• Industrial quality control and metrology labs

• Automotive and mechanical workshop inspection
