Bimetal Thermometer – Industrial Stainless Steel Temperature Gauge for HVAC, Boilers & Process Systems
Official Store
Quote Required
Institutional / Custom Order
Price is customized based on project specifications, quantity, and requirements. Click below for an official quotation.
Instant RFQ Submission
Official VAT / Commercial Invoice
Fast Response within 2-4 Hours
100% Authentic
Genuine Brand Guarantee
Cash on Delivery
Pay When You Receive
7-Day Warranty
Hassle-Free Replacement
1
TIG Welding Tungsten Electrode 2.4mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#2
TIG Welding Tungsten Electrode 1.6mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#3
Solder Crystal Rosin Flux BK-220 by BAKU – Clean Soldering, Smooth Connections
#4
Bambu Lab PLA Matte Ivory White Filament 1.75mm – Premium 3D Printing Material for Smooth, Precise Prints
#5
Beelayers Pla+ Black 3D Printer Filament 1.75mm
#6
Beelayers PLA+ White 3D Printer Filament 1.75mm – High Strength PLA Plus Filament for FDM 3D Printing
A bimetal thermometer is a mechanical temperature-sensing device designed for accurate and reliable temperature measurement in industrial systems. It uses a bimetallic strip that expands or contracts with temperature changes, causing the pointer to rotate on a calibrated dial. This thermometer is widely used in applications requiring direct, real-time temperature readings without external power.
Engineered for durability and precision, the bimetal thermometer is ideal for HVAC systems, pipelines, tanks, boilers, and mechanical equipment in manufacturing, power generation, and processing industries. Available in various dial sizes, stem lengths, and connection types, it is suitable for a wide range of operating environments.
features:
-
Accurate and maintenance-free mechanical temperature measurement
-
Rugged stainless steel housing for corrosion resistance
-
Fast response time with high repeatability
-
Adjustable or fixed stem options available
-
Back, bottom, or every-angle dial mounting configurations
-
Compatible with thermowells for high-pressure or corrosive applications
Applications:
-
Industrial process monitoring
-
Oil and gas pipelines
-
Boilers and heat exchangers
-
HVAC and refrigeration systems
-
Chemical and petrochemical industries
-
Water treatment and power plants
Technical specifications:
| Parameter | Specification |
|---|---|
| Measurement principle | Bimetallic coil (mechanical temperature sensing) |
| Dial sizes | 63 mm, 100 mm, 150 mm (custom sizes available) |
| Temperature ranges | -50°C to +600°C / -58°F to +1112°F (model dependent) |
| Accuracy class | Class 1.0 / Class 1.6 (per EN 13190 or ASME B40.3) |
| Stem material | Stainless steel (SS304, SS316) |
| Stem diameter | 6 mm, 8 mm, 10 mm (others on request) |
| Stem length | 50 mm to 1000 mm |
| Connection type | Bottom, back, or adjustable angle; threaded (BSP/NPT) |
| Mounting options | Direct, surface, or remote via capillary |
| Case material | Stainless steel, IP65 or higher rated |
| Operating environment | Suitable for indoor and outdoor industrial use |
| Optional features | Dampened movement, silicone-filled case, safety glass window |
| Standards compliance | ASME B40.3, EN 13190, ISO 9001 manufacturing |
| Parameter | Specification |
|---|---|
| Measurement principle | Bimetallic coil (mechanical temperature sensing) |
| Dial sizes | 63 mm, 100 mm, 150 mm (custom sizes available) |
| Temperature ranges | -50°C to +600°C / -58°F to +1112°F (model dependent) |
| Accuracy class | Class 1.0 / Class 1.6 (per EN 13190 or ASME B40.3) |
| Stem material | Stainless steel (SS304, SS316) |
| Stem diameter | 6 mm, 8 mm, 10 mm (others on request) |
| Stem length | 50 mm to 1000 mm |
| Connection type | Bottom, back, or adjustable angle; threaded (BSP/NPT) |
| Mounting options | Direct, surface, or remote via capillary |
| Case material | Stainless steel, IP65 or higher rated |
| Operating environment | Suitable for indoor and outdoor industrial use |
| Optional features | Dampened movement, silicone-filled case, safety glass window |
| Standards compliance | ASME B40.3, EN 13190, ISO 9001 manufacturing |
