Water Level Sensor Cable Type Liquid Fluid Floating Switch

Water Level Sensor Cable Type Liquid Fluid Floating Switch

The Cable Type Liquid Fluid Floating Switch is a reliable and cost-effective solution for monitoring and controlling water or liquid levels in tanks, wells, reservoirs, and industrial systems. Designed to float on the surface of liquids, this switch uses a mechanical float to detect changes in water levels and activates or deactivates pumps, valves, or alarms accordingly.

Key Features:

? Float-Type Mechanism
The switch operates through a buoyant float that rises and falls with the liquid level. When the float tilts to a specific angle (typically 45°), it activates the internal micro switch to open or close an electrical circuit.

? Durable Cable Construction
Equipped with a flexible, waterproof cable (usually ranging from 2 to 10 meters), the sensor can be easily installed at various depths. The cable is made of high-quality PVC or neoprene material that is resistant to oil, acids, and corrosion.

? Versatile Liquid Compatibility
Suitable for both clean and dirty water, as well as non-corrosive chemical liquids. Common applications include sump pits, water tanks, septic systems, irrigation systems, and industrial tanks.

? Automatic Pump Control
Can be wired for automatic filling or emptying functions—ideal for water pumps to avoid dry run or overflow scenarios.

? No Power Consumption
This float switch is passive and does not require any external power source for the sensor itself—only the connected control equipment requires power.

? IP68 Waterproof Rating
The sealed float housing ensures long-term operation under submerged conditions, offering excellent water resistance and reliability.

Technical Specifications:

• Sensor Type: Mechanical Float Switch

• Operation: Tilt Angle Activation (typically 45°)

• Cable Length: 2m / 3m / 5m / 10m (custom lengths available)

• Contact Type: SPDT (Single Pole Double Throw) or SPST (optional)

• Rated Voltage: 220V AC / 110V AC

• Rated Current: 10A (resistive load)

• Working Temperature: 0°C to 80°C

• Material: Polypropylene (PP) Float + PVC/Neoprene Cable

• Protection Class: IP68

• Certification: CE, RoHS

Applications:

• Domestic and industrial water tank level control

• Sump pump systems in basements

• Agricultural irrigation systems

• Sewage treatment plants

• Chemical storage tanks (non-corrosive liquids)

• Aquariums, fish farms, and hydroponics systems

Installation & Wiring:

• Easy to Install – Simply hang the float switch inside the tank or fix it to a pipe or wall.

• Flexible Wiring Options – Can be connected to operate in either normally open (NO) or normally closed (NC) mode depending on whether the application needs to start or stop equipment at a certain water level.

Why Choose This Product?

✅ Long-lasting and reliable performance
✅ Simple mechanical design—no complex electronics
✅ Affordable yet highly efficient
✅ Wide compatibility with different liquids and pump systems
✅ Safe operation with high current capacity
