UNI-T UTi320E Industrial Infrared Thermal Imager Camera with WiFi and PC Software Monitoring Function
Official Store
৳83,500.00
৳85,500.00
-2% OFF
/pcs
Inclusive of all taxes
Best Price Guarantee
Delivery in 4 Days
100% Authentic
Genuine Brand Guarantee
Cash on Delivery
Pay When You Receive
7-Day Warranty
Hassle-Free Replacement
1
TIG Welding Tungsten Electrode 2.4mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#2
TIG Welding Tungsten Electrode 1.6mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#3
Solder Crystal Rosin Flux BK-220 by BAKU – Clean Soldering, Smooth Connections
#4
Bambu Lab PLA Matte Ivory White Filament 1.75mm – Premium 3D Printing Material for Smooth, Precise Prints
#5
Beelayers Pla+ Black 3D Printer Filament 1.75mm
#6
Beelayers PLA+ White 3D Printer Filament 1.75mm – High Strength PLA Plus Filament for FDM 3D Printing
Description
UTi320E is an advanced professional handheld Thermal Imaging Camera for diagnosing electrical, mechanical, HAVC and building problems etc. It features powerful functions with user-friendly operation interface. The camera supports high IR resolution of 320 x 240 which helps to find abnormal temperature points easily. Its measuring temperature is expanded from -40°C to 400°C, suitable for a wide range of applications.
One of the outstanding feature is the embedded Wi-Fi, which allows users to quickly connect the camera. Then share images and send reports easily from any location. Besides, PC software is available for image analysis, generating reports and giving external alarm alert. Meanwhile, the PC software real-time screen could be projected to monitor.
The device reaches IP54 protection level and 2 meters drop resistance. It is stable and durable.
One of the outstanding feature is the embedded Wi-Fi, which allows users to quickly connect the camera. Then share images and send reports easily from any location. Besides, PC software is available for image analysis, generating reports and giving external alarm alert. Meanwhile, the PC software real-time screen could be projected to monitor.
The device reaches IP54 protection level and 2 meters drop resistance. It is stable and durable.
Features
√ IR resolution 320*240
√ 3.5″ large IPS Screen
√ Temperature Range:-40℃ ~400℃
√ Thermal Camera and Visible Light Camera
√ 16G Miscro SD Card for pictures Storage
√ Auto-tracking and Auto-alarm of High/Low Temperature
√ PC Software monitoring and analysis
√ WiFi connection to cellphone
√ IP54Waterproof and 2M drop test
√ 3.5″ large IPS Screen
√ Temperature Range:-40℃ ~400℃
√ Thermal Camera and Visible Light Camera
√ 16G Miscro SD Card for pictures Storage
√ Auto-tracking and Auto-alarm of High/Low Temperature
√ PC Software monitoring and analysis
√ WiFi connection to cellphone
√ IP54Waterproof and 2M drop test
Specifications
Model: UTi320E
General Characteristics
IR resolution: 320×240 pixel
Screen Display: 3.5”IPS
Field of view (FOV): 56°x 42°
Thermal sensitivity (NETD): 65mK
Spatial resolution (IFOV): 3mrad
Focus: Focus free
Frame rate: 9Hz
Object Temperature range: -40~400℃
Measurement accuracy: ±2℃ or ±2% whichever is greater
Battery: Li-ion battery pack(5200mAh)
Battery Type: Replaceable
Battery operating time: ≧4 hours
Founctions
Palettes: 7
Emissivity: Adjustable (0.01-0.99)
Measurement presets: Point x5, Line x1, Area x6
Digital camera: 2MP
Digital zoom: 2x, 4x
Image Model: Thermal, visible, blending, PiP
LED: √
WiFi download photo: √
ROI (eliminates interference): √
Isotherm: √
Atuo tracking for Lo/Hi temperature: √
Alarm: √
Storage: 16G Mcro SD Card
PC software: Analysis, Realtime display
Protection: IP54/2m
Communication interface: Type-C
General Characteristics
IR resolution: 320×240 pixel
Screen Display: 3.5”IPS
Field of view (FOV): 56°x 42°
Thermal sensitivity (NETD): 65mK
Spatial resolution (IFOV): 3mrad
Focus: Focus free
Frame rate: 9Hz
Object Temperature range: -40~400℃
Measurement accuracy: ±2℃ or ±2% whichever is greater
Battery: Li-ion battery pack(5200mAh)
Battery Type: Replaceable
Battery operating time: ≧4 hours
Founctions
Palettes: 7
Emissivity: Adjustable (0.01-0.99)
Measurement presets: Point x5, Line x1, Area x6
Digital camera: 2MP
Digital zoom: 2x, 4x
Image Model: Thermal, visible, blending, PiP
LED: √
WiFi download photo: √
ROI (eliminates interference): √
Isotherm: √
Atuo tracking for Lo/Hi temperature: √
Alarm: √
Storage: 16G Mcro SD Card
PC software: Analysis, Realtime display
Protection: IP54/2m
Communication interface: Type-C
Technical Specifications
Official specifications for UNI-T UTi320E Industrial Infrared Thermal Imager Camera with WiFi and PC Software Monitoring Function.
| Specification | Details |
|---|---|
| Product Name | UNI-T UTi320E Industrial Infrared Thermal Imager Camera with WiFi and PC Software Monitoring Function |
| Category | Tools and Equipment |
| Unit | pcs |
| Power Compatibility | 220V AC, 50Hz (Standard Bangladesh Grid Compatible) |
| Warranty & Service | Official Warranty & Technical Support at Industrial 3D Solution, Dhaka |
| Delivery Coverage | Fast Delivery inside Dhaka & Nationwide Courier to all 64 Districts |
