TSGC2 9KW Three Phase Variac – Industrial-Grade Voltage Regulator & Variable Transformer for Precision Power Control

Overview:

The TSGC2 9KW Three Phase Variac is a precision-engineered, heavy-duty adjustable voltage transformer specifically designed for industrial and commercial-grade electrical applications. Built to regulate voltage with exceptional accuracy and reliability, this variac delivers stable, continuous, and distortion-free voltage output across a wide range of equipment, reducing energy waste, minimizing load fluctuations, and protecting sensitive components from voltage spikes or drops.

Unlike conventional fixed-output transformers, this manual voltage controller allows for fine voltage adjustments between 0V and the rated maximum (typically up to 430V) across all three phases, giving complete control to the operator for calibration, testing, or customized voltage output. Whether you're operating machinery, balancing power loads, or testing variable input devices, the TSGC2 offers seamless and responsive voltage control with exceptional thermal stability and overload protection.

Technical Specifications:

• Model: TSGC2-9KW

• Rated Power: 9000 Watts (9KW)

• Input Voltage: 380V (±10%), Three Phase, 50/60Hz

• Output Voltage: Adjustable from 0V to 430V (Line-to-Line)

• Phase Configuration: Three Phase

• Frequency: 50Hz / 60Hz

• Control Type: Manual rotary dial (carbon brush mechanism)

• Efficiency: ≥ 95%

• Cooling Method: Natural air cooling

• Insulation Resistance: ≥ 5 MΩ

• Dielectric Strength: 2000V/min

• Construction: High-quality copper winding, silicon steel core, powder-coated metal housing

• Protection: Overvoltage, overload, short circuit (fuse or breaker optional)

• Noise Level: Low-noise operation, < 50dB

• Dimensions & Weight: Varies by manufacturer (approx. 45-55kg)

Key Features & Functional Advantages:

• Precision Voltage Adjustment:
  Easily regulate output voltage from 0 to rated voltage for real-time voltage testing or load balancing, with no waveform distortion.

• High Efficiency & Low Loss:
  Optimized coil design with premium copper winding ensures low core losses and high energy conversion efficiency.

• Industrial Build Quality:
  Rugged mechanical structure with heat-treated core laminations and corrosion-resistant body ensures long-term reliability in harsh industrial environments.

• Three Phase Synchronization:
  Maintains balanced output across three phases, protecting connected loads from imbalance-related damage or performance drops.

• Manual Rotary Dial Control:
  Smooth carbon brush and coil contact system provide durable and precise manual adjustment of output voltage with minimal wear.

• Safety First:
  Designed with insulation, overload protection, thermal tolerance, and optional circuit breakers or fuses to ensure safety in continuous use.

Typical Industrial Applications:

• Power Supply for CNC Machines & Industrial Tools

• Testing & Calibration of Electrical Equipment

• HVAC Systems & Fan Speed Control

• Voltage Regulation in Welding Machines

• Lighting Load Testing & Power Simulation

• Industrial Automation & Control Panels

• Educational Institutions & Training Labs
