Rigol DS2302A 300MHz Digital Storage Oscilloscope – 2 Channel High-Bandwidth DSO with Deep Memory & Advanced Signal Analysis
Official Store
৳134,560.00
/PC
Inclusive of all taxes
Best Price Guarantee
Delivery in 15 Days
100% Authentic
Genuine Brand Guarantee
Cash on Delivery
Pay When You Receive
7-Day Warranty
Hassle-Free Replacement
1
TIG Welding Tungsten Electrode 2.4mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#2
TIG Welding Tungsten Electrode 1.6mm – Premium High-Performance TIG Rods for Stainless Steel & Mild Steel Welding
#3
Solder Crystal Rosin Flux BK-220 by BAKU – Clean Soldering, Smooth Connections
#4
Bambu Lab PLA Matte Ivory White Filament 1.75mm – Premium 3D Printing Material for Smooth, Precise Prints
#5
Beelayers Pla+ Black 3D Printer Filament 1.75mm
#6
Beelayers PLA+ White 3D Printer Filament 1.75mm – High Strength PLA Plus Filament for FDM 3D Printing
The Rigol DS2302A is a powerful 300MHz bandwidth digital storage oscilloscope with 2 independent channels designed for precise waveform analysis, fast real-time sampling, and complex signal troubleshooting. Ideal for engineers, technicians, and researchers, this DSO combines advanced features with easy operation, ensuring accurate capture and analysis of high-speed signals.
Key Features:
-
300MHz bandwidth for accurate high-frequency signal acquisition
-
Dual analog input channels for simultaneous multi-signal measurement
-
Real-time sampling rate up to 2 GSa/s for capturing fast transient signals
-
Deep memory depth up to 14 million points (14Mpts) to record long waveform sequences without data loss
-
Advanced triggering modes including edge, pulse width, slope, video, pattern, and serial bus triggers
-
Serial protocol decoding support for I2C, SPI, UART, CAN, and LIN buses
-
Large 8-inch WVGA color display with 800×480 resolution for clear waveform visualization
-
High waveform capture rate of up to 50,000 waveforms per second
-
USB, LAN, and RS-232 interfaces for easy PC connectivity and remote control
-
Compact and rugged design perfect for lab benches or portable use
Technical Specifications:
| Parameter | Specification |
|---|---|
| Bandwidth | 300 MHz |
| Channels | 2 Analog Input Channels |
| Real-Time Sampling Rate | Up to 2 GSa/s |
| Memory Depth | Up to 14 Mpts |
| Waveform Capture Rate | Up to 50,000 waveforms/second |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Input Impedance | 1 MΩ ± 2% |
| Time Base Range | 5 ns/div to 50 s/div |
| Trigger Types | Edge, Pulse Width, Slope, Video, Pattern, Serial Bus Trigger |
| Serial Protocol Decoding | I2C, SPI, UART/RS232, CAN, LIN |
| Display | 8-inch Color TFT LCD (800×480 pixels) |
| Interface | USB Host, USB Device, LAN (VXI-11), RS-232 |
| Power Supply | 100–240 V AC, 45–440 Hz |
| Dimensions (W×H×D) | Approx. 361 mm × 179 mm × 112 mm |
| Weight | Approx. 3.6 kg |
Applications:
-
Embedded system development and debugging
-
Power electronics and switching circuit analysis
-
Analog and mixed-signal circuit testing
-
Educational and research laboratories
-
Industrial maintenance and fault diagnostics
Why Choose Rigol DS2302A?
The Rigol DS2302A merges high bandwidth and deep memory with advanced triggering and analysis capabilities, delivering exceptional precision for professional electronics testing. Its robust design and user-friendly interface make it a trusted instrument for engineers and technicians in various industries.
| Parameter | Specification |
|---|---|
| Bandwidth | 300 MHz |
| Channels | 2 Analog Input Channels |
| Real-Time Sampling Rate | Up to 2 GSa/s |
| Memory Depth | Up to 14 Mpts |
| Waveform Capture Rate | Up to 50,000 waveforms/second |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Input Impedance | 1 MΩ ± 2% |
| Time Base Range | 5 ns/div to 50 s/div |
| Trigger Types | Edge, Pulse Width, Slope, Video, Pattern, Serial Bus Trigger |
| Serial Protocol Decoding | I2C, SPI, UART/RS232, CAN, LIN |
| Display | 8-inch Color TFT LCD (800×480 pixels) |
| Interface | USB Host, USB Device, LAN (VXI-11), RS-232 |
| Power Supply | 100–240 V AC, 45–440 Hz |
| Dimensions (W×H×D) | Approx. 361 mm × 179 mm × 112 mm |
| Weight | Approx. 3.6 kg |
