Havells 8-Way SPN Double Door Distribution Board – Heavy-Duty Electrical Panel for Safe Power Distribution & Circuit Protection

Havells 8-Way SPN Double Door Distribution Board – Heavy-Duty Electrical Panel for Safe Power Distribution & Circuit Protection

Product Overview

The Havells 8-Way SPN Distribution Board Double Door is designed for reliable and safe power distribution across multiple circuits in homes, offices, and light industrial applications. With an SPN (Single Pole + Neutral) configuration and double-door design, this board ensures neat installation, safety, and easy maintenance.

Built from powder-coated CRCA steel (0.8 mm thickness), the board provides durability, corrosion resistance, and long-term reliability. Its IP42 rating protects against solid particles over 1 mm and water drips, making it safe for residential and semi-industrial environments. The copper bus bars (100 A) with tin plating and nickel-plated brass neutral and earth bars ensure stable current flow and excellent electrical conductivity.

This board supports surface and flush mounting, providing installation flexibility. Its compliance with IEC 61439-3, IS 13032, and IS 8623 standards guarantees safe operation and regulatory conformity.

Key Features

• 8 Modular Ways — Accommodates up to 8 MCBs or modular devices.

• SPN Configuration — Ensures neutral availability for each circuit.

• Double-Door Enclosure — Protects wiring, provides security, and allows easy access.

• Durable Construction — Powder-coated CRCA steel sheet (0.8 mm thick) for strength and corrosion resistance.

• Copper Bus Bar (Tin-Plated) — Provides consistent current flow and minimal resistance.

• Nickel-Plated Brass Neutral & Earth Bars — Ensures corrosion resistance and reliable connections.

• IP42 Protection — Guards against solid object intrusion (>1 mm) and light water drips.

• Compliance with Standards — IEC 61439-3, IS 13032 & IS 8623 compliant.

• Flexible Mounting Options — Suitable for surface or flush mounting.

• Fault Capacity — 5 kA for 100 ms fault current duration.

• Ambient Temperature Range — Operates safely from 0 °C to 50 °C.

Technical Specifications

Applications & Use Cases

• Residential Homes — Central distribution for lighting, sockets, and appliances.

• Commercial Offices & Shops — Safe power distribution for multiple circuits.

• Light Industrial / Workshops — Manage circuits for small machines, lighting, and equipment.

• Retail Outlets & Malls — Reliable power control for lighting and electrical devices.

• Renovation Projects — Replace old panels with modern SPN double-door boards.

Benefits & Competitive Advantages

• Safe Power Management — Centralized control of circuits under a protected enclosure.

• Enhanced Safety — Double-door design, insulated bars, and IP42 protection prevent accidental touch and hazards.

• Durable Construction — Powder-coated steel and plated conductors resist wear, heat, and corrosion.

• Flexible Installation — Supports both surface and flush mounting for versatile deployment.

• Compact & Neat — Efficient internal layout with DIN rails and neutral/earth bars.

• Standards-Compliant — Meets international and Indian electrical standards.

• Future-Ready Capacity — Modular slots allow expansion or replacement of MCBs.

• User-Friendly Maintenance — Easy access for wiring, inspection, and upgrades.
