FNIRSI 1014D 2-in-1 Dual Channel Digital Oscilloscope & Signal Generator – 100MHz Bandwidth, 1GS/s Sampling Rate, Multifunction Waveform Analyzer for Electronics & Circuit Testing

FNIRSI 1014D – Professional 2-in-1 Dual Channel Digital Oscilloscope & Signal Generator

The FNIRSI 1014D is a high-performance multifunction electronic testing instrument that combines a dual-channel 100MHz digital storage oscilloscope with an integrated signal generator, providing a complete solution for signal measurement, waveform analysis, and electronic circuit diagnostics. This 2-in-1 device is ideal for professional engineers, field technicians, electronics hobbyists, and educational laboratories seeking reliable, accurate, and portable testing capabilities.

Unmatched Oscilloscope Performance

The oscilloscope function delivers 100MHz analog bandwidth and a blazing 1GS/s real-time sampling rate, ensuring every detail of fast-changing waveforms is captured with high fidelity.

• Dual Independent Channels allow simultaneous monitoring of two signals, enabling side-by-side comparison for more efficient troubleshooting.

• Deep Memory Depth ensures long waveform captures without loss of resolution, making it easier to analyze slow and fast events together.

• Advanced Triggering Options (Edge, Pulse, Video, Slope, Alternate) allow precise capture of desired signals, even in noisy environments.

• Automatic Measurements for frequency, voltage peak-to-peak, RMS, duty cycle, and rise/fall time simplify complex analysis.

Built-in High-Precision Signal Generator

The integrated DDS (Direct Digital Synthesis) signal generator makes the FNIRSI 1014D a complete lab tool:

• Generate multiple waveforms including sine, square, triangle, pulse, and arbitrary custom waveforms.

• Adjustable frequency, amplitude, and duty cycle for component testing, calibration, and simulation.

• Perfect for injecting test signals into a circuit to verify system performance or locate faults.

Professional Display & User Experience

The FNIRSI 1014D features a 7-inch TFT LCD color display with 800×480 resolution, delivering sharp, clear, and vibrant waveform visuals.

• Intuitive Menu Interface: Simplifies operation with clearly labeled soft keys and quick-access buttons.

• Multiple Display Modes: Persist mode, XY mode, and split display for dual-channel viewing.

• Portable yet Rugged Design: Ideal for field service and workshop environments, with a durable casing to protect against daily wear.

Connectivity & Data Management

• USB Data Interface: Save captured waveforms, screenshots, and measurement data directly to a PC.

• Firmware Upgrade Support: Keep your device updated with the latest features and improvements.

• Screenshot & Storage: Instantly capture important waveforms for documentation or reporting.

Key Technical Specifications

Applications

• Electronics Design & Development – Ideal for prototyping and R&D work.

• PCB Fault Diagnosis – Quickly identify defective circuits and components.

• Microcontroller & Embedded Systems Testing – Analyze and debug digital and analog signals.

• Power Electronics – Evaluate switching waveforms, inverters, and power supplies.

• Audio & RF Applications – Measure, analyze, and troubleshoot audio or radio-frequency signals.

• Educational Training – Perfect for electronics laboratories in universities and vocational schools.
