The DNC Series ISO6431 Standard Cylinder is a high-performance pneumatic actuator designed to meet ISO6431 standards for industrial automation and mechanical applications. Built with precision and durability in mind, this cylinder offers reliable performance, long service life, and easy integration into various systems.

Key Features:

1. Compliance with ISO6431 Standards: Ensures compatibility with a wide range of pneumatic systems and accessories.
2. Material: Constructed from high-quality aluminum alloy for lightweight strength and resistance to corrosion.
3. Double-Acting Operation: Provides efficient bidirectional movement for versatile application needs.
4. Air Cushion Option: Reduces impact at the end of the stroke, extending cylinder life and enhancing operational smoothness.
5. Wide Range of Bore Sizes and Strokes:
   • Bore sizes: 32mm to 160mm
   • Stroke lengths: 25mm to 2000mm
6. Adjustable Cushion Stroke: Up to 32mm for precise control and reduced wear during operation.
7. Operating Pressure Range: 0.1 to 0.9 MPa, making it suitable for various pneumatic systems.
8. Temperature Range: Operates effectively between -5°C and 70°C.

Applications:

The DNC Series ISO6431 Cylinder is ideal for a variety of applications in industries such as:

• Automotive: For assembly lines and material handling.
• Packaging: Used in machines for sealing, cutting, and filling.
• Textile: Drives machinery for weaving and spinning.
• Manufacturing: Involved in robotic arms, conveyor systems, and more.

Advantages:

• Standardized Design: Easy interchangeability with other ISO6431-compliant cylinders.
• High Efficiency: Smooth and accurate linear motion with minimal air leakage.
• Durability: Aluminum alloy body ensures resilience in demanding environments.
• Flexibility: Available in multiple configurations, such as air cushioning, adjustable stroke, and flange mounting options.

Technical Specifications:

• Operating Medium: Filtered compressed air (40μm filter recommended).
• Port Sizes: Ranges from 1/8” to 1/2” depending on bore size.
• Maximum Stroke: 2000mm.
• Pressure Resistance: Proof pressure of up to 1.35 MPa ensures safety during operation.
