DLWD-DJ22-M Induction Motor Training System

The DLWD-DJ22-M Induction Motor Training System is a complete, hands-on educational solution developed for teaching the operating principles, control methods, and performance analysis of induction motors. Designed for use in vocational institutions, technical colleges, engineering faculties, and industrial training centers, this system offers students a practical approach to understanding three-phase and single-phase induction motor technologies.

This training system integrates real industrial components, allowing learners to perform experiments related to motor starting, braking, speed control, fault simulation, and energy efficiency analysis. The system is designed in accordance with modern curriculum requirements for electrical engineering, industrial automation, and mechatronics programs.

 Features

• Suitable for single-phase and three-phase induction motor training

• Includes real industrial motors, contactors, overload relays, meters, and switches

• Covers various starting methods such as direct-on-line, star-delta, soft start, and variable frequency drive (VFD)

• Enables braking, reversing, and speed control exercises with adjustable load modules

• Integrated instrumentation for current, voltage, power, and rotational speed measurement

• Fault simulation module for testing response and troubleshooting skills

• Clearly labeled terminals and safety terminals for safe circuit configuration

• Modular panel system mounted on a wheeled steel frame for easy classroom mobility

• Conforms to technical training standards used in industrial certification programs

Technical Specifications

• Model: DLWD-DJ22-M

• Power supply: AC 380V three-phase, 50Hz

• Output: AC three-phase and DC low voltage for control circuits

• Motor types: squirrel cage induction motor and wound rotor motor

• Starting methods: direct-on-line, star-delta, soft start, VFD-based control

• Metering: digital voltmeter, ammeter, power meter, and tachometer

• Control modules: thermal overload relay, timer relay, push buttons, indicator lights

• Safety: emergency stop, short circuit and overload protection

• Frame: steel structure with anti-static, modular panels

• Dimensions: approximately 1600 mm x 800 mm x 1700 mm

• Compliance: ISO and CE certified; suitable for technical education and vocational training standards

  aplication

• Vocational schools offering electrical and mechanical technology programs

• Polytechnic and engineering institutes teaching motor control and power systems

• Industrial training centers for technician upskilling and maintenance staff development

• Competency-based assessment programs aligned with national skill standards

• Practical laboratories in mechatronics, automation, and power electronics courses

DLWD-DJ22-M Induction Motor Training System

The DLWD-DJ22-M provides a real-world, interactive learning experience with industrial-grade components that mirror actual workplace conditions. Its modular design and safe interface make it ideal for both teaching and assessment. The system supports a variety of motor-related experiments, including operational behavior, electrical parameter analysis, fault detection, and control logic, helping students gain job-ready skills in motor systems and electrical engineering.
