Digital Storage Oscilloscope TDS2024C is a high-performance, portable, and versatile oscilloscope ideal for signal analysis and debugging tasks in engineering and electronics applications. Manufactured by Tektronix, the TDS2024C offers advanced features designed for accurate waveform capture, easy operation, and reliable performance.

Features:

• Bandwidth: 200 MHz, suitable for analyzing high-frequency signals.
• Channels: 4 analog input channels, enabling simultaneous monitoring of multiple signals.
• Sampling Rate: Up to 2 GS/s (gigasamples per second) for high-resolution signal acquisition.
• Display: Large 5.7-inch color LCD screen for clear waveform visualization.
• Storage: 2.5k point record length per channel for extended signal capture.
• USB Connectivity: Easily connect to a PC or external storage for data transfer and analysis.
• User-friendly Interface: Simple menu structure and dedicated knobs for time, voltage, and channel settings.
• Triggering Functions: Advanced triggering options including edge, pulse width, and video, for precise signal measurement.
• FFT Analysis: Built-in FFT function for frequency domain analysis.
• Compact Design: Lightweight and portable, perfect for field and laboratory use.

Specifications:

• Bandwidth: 200 MHz
• Sampling Rate: 2 GS/s
• Channels: 4
• Display: 5.7-inch TFT LCD
• Vertical Resolution: 8 bits
• Vertical Sensitivity: 2 mV to 5 V/div
• Time Base Range: 4 ns to 100 s/div
• Memory Depth: 2.5k points per channel
• Trigger Modes: Edge, pulse width, video
• Connectivity: USB host and device ports
• Dimensions: 12.12 x 5.97 x 4.96 inches
• Weight: 4.4 lbs (2 kg)
