? Product Overview

The DELIXI CJX2S-1210 is a high-performance AC magnetic contactor designed for remote switching and control of electrical circuits. With a compact design and robust construction, it is ideal for applications involving the frequent starting, stopping, and reversing of AC motors. This contactor is suitable for use in motor control centers, distribution boards, and industrial automation systems.​achasoda.com

⚙️ Key Features

• Rated Operational Current (Ie): 25A at 380/400V AC-3

• Control Circuit Voltage (Uc): 220V AC

• Rated Insulation Voltage (Ui): 690V

• Rated Impulse Withstand Voltage (Uimp): 8kV

• Mechanical Endurance: Up to 1 million operations

• Electrical Endurance: Up to 100,000 operations under AC-3 duty

• Number of Poles: 3P (Three-phase)

• Auxiliary Contacts: 1 Normally Open (NO)

• Standards Compliance: IEC 60947-4-1, GB 14048.4

• Certifications: CE, CCC​achasoda.com+4Delixi Electric+4mhhoist.en.made-in-china.com+4turnmooner.com+1Delixi Electric+1mhhoist.en.made-in-china.com+3mhhoist.en.made-in-china.com+3achasoda.com+3turnmooner.com+3achasoda.com+3mhhoist.en.made-in-china.com+3

? Applications

• Controlling and protecting three-phase motors in industrial settings

• Integration into motor starters with thermal overload relays

• Use in automation systems for machinery control

• Suitable for HVAC systems, pumps, compressors, and conveyors​Delixi Electricachasoda.com

? Dimensions & Installation

• Width (Amax): 56 mm

• Height (Bmax): 84 mm

• Depth (Cmax): 93 mm

• Mounting Hole Distance (a): 40 ± 0.5 mm

• Mounting Hole Distance (b): 50 ± 0.5 / 60 ± 0.6 mm

• Mounting Hole Diameter (φ): 4.5 mm​achasoda.com+2mhhoist.en.made-in-china.com+2mhhoist.en.made-in-china.com+2achasoda.com+2mhhoist.en.made-in-china.com+2mhhoist.en.made-in-china.com+2

?️ Accessories & Compatibility

• Auxiliary Contact Blocks: Compatible with LA1-DN series (e.g., LA1-DN11 for 1NO+1NC)

• Time Delay Blocks: Supports LA2-DT series for on-delay and LA3-DR series for off-delay functions

• Thermal Overload Relays: Can be combined with appropriate thermal relays to form a complete motor starter​
