The AW Series F.R. Combination Filter+Regulator Air Treatment Unit is designed to effectively manage and optimize compressed air systems by providing filtration, pressure regulation, and lubrication. The key features and specifications are outlined below:

Product Features:

• Air Filter/Regulator (F+R): Combines filtration and regulation in one compact unit for efficient air treatment.
• Thread Options: Available with RC (PT), G (PF), or NPT threads for versatile installation.
• Port Sizes: Options include 1/8", 1/4", 3/8", and 1/2" for flexible system compatibility.
• Ease of Maintenance: Designed for simplicity, ensuring easy maintenance and operation with a long service life.

Specifications:

• Models:
  • AW2000-01/02
  • AW3000-02/03
  • AW4000-03/04
  • AW4000-06
  • AW5000-06/10
• Port Sizes:
  • AW2000: 1/8", 1/4"
  • AW3000: 1/4", 3/8"
  • AW4000: 3/8", 1/2"
  • AW4000-06: 3/4"
  • AW5000: 3/4", 1"
• Pressure Gauge Size: 1/8" for AW2000, 1/4" for others
• Working Medium: Air
• Pressure Range: 0.05 to 0.85 MPa
• Flow Rate:
  • AW2000: 750 L/min
  • AW3000: 1500 L/min
  • AW4000: 4000 L/min
  • AW4000-06: 6000 L/min
  • AW5000: 7000 L/min
• Filter Precision: Standard 5 μm for optimal air filtration
