The Altivar Process ATV630 is a robust and energy-efficient variable speed drive specifically designed for industrial applications that require precision and reliability in motor control. This drive is focused on energy savings, fluid management, and operational flexibility, making it an ideal choice for industries such as water and wastewater, mining, oil and gas, food and beverage, and more.

Key Features:

1. Powerful Motor Compatibility:

   • Supports 3-phase synchronous and asynchronous motors.
   • Handles motor power ratings up to 30 kW / 40 hp for slight overload applications (120%).
   • Suitable for motors up to 22 kW / 30 hp for significant overload applications (150%).

2. Energy-Saving Innovation:

   • Provides up to 30% energy savings during standby with the "Stop and Go" operation.

3. Built-in Communication Ports:

   • 3 RJ45 Ports: Ensure seamless connectivity for control and monitoring.
   • 1 Ethernet Port and 2 Serial Ports for versatile communication options.

4. Integrated EMC Filters:

   • C2 Compliance: Up to 50m.
   • C3 Compliance: Up to 150m.

5. Durable Design:

   • Rated IP21 for protection against dust and moisture (IEC 60529, IEC 61800-5-1).
   • Equipped with forced convection cooling for consistent performance.

Specifications:

• Product Type: Variable Speed Drive
• Model: Altivar Process ATV630 (Standard Version)
• Voltage Range: 380V to 480V AC
• Rated Supply Voltage: [Us] 380-480 V
• Dimensions: 226mm (W) x 673mm (H) x 271mm (D)
• Weight: 28 kg
• Mounting Position: Vertical (±10°) wall-mounted installation
• Cooling Method: Forced convection

Additional Accessories and Options:

• Accessories Available: Fan kits, graphic display terminals.
• Optional Modules: I/O expansion modules, communication modules, EMC input filters.

Applications:

This drive is tailored for energy management and performance optimization in the following industries:

• Water and Wastewater: Fluid processing and control.
• Mining, Minerals, and Metals: Heavy-duty motor control.
• Oil and Gas: Precision operations in critical environments.
• Food and Beverage: High-performance motor control for processing equipment.
