Ignition Transformer for Gas Burner 18KV | 220V AC 50-60Hz Heavy-Duty Boiler & Furnace Spark Ignition Power Module

The Ignition Transformer Gas Burner 18KV, 220V AC, 50–60Hz is a high-performance ignition system engineered for industrial gas burners, boilers, furnaces, and heat-processing equipment. Designed for continuous and demanding industrial environments, this transformer delivers stable 18,000-volt ignition power, ensuring fast spark generation, reliable burner startup, and consistent performance under varying load and temperature conditions.

Its rugged construction, high-grade insulation, and efficient magnetic core design provide long operational life, making it a preferred choice for OEMs, burner service professionals, and industrial plants that require reliable ignition safety.

Features

• High-Voltage 18KV Output for consistent and powerful spark ignition
• 220V AC Input Compatibility for universal industrial electrical systems
• 50–60Hz Frequency Range suitable for global installations
• Optimized Magnetic Core ensuring stable voltage transformation
• Thermal-Resistant Coil Winding for long operational durability
• Short-Circuit Protection Design preventing coil damage
• High-Grade Epoxy Resin Seal for moisture and dust resistance
• Fast Ignition Response Time improving burner startup reliability
• Low Power Consumption with optimized efficiency
• Compact Heavy-Duty Housing suitable for confined industrial spaces
• Vibration-Resistant Mounting for boiler room applications
• Maintenance-Free Operation with long service life

Specifications

• Output Voltage: 18KV
• Input Voltage: 220V AC
• Frequency Range: 50–60Hz
• Primary Current: 0.3A–0.6A (typical depending on load)
• Secondary Current: High-voltage pulse output
• Core Type: Laminated silicon steel magnetic core
• Insulation Class: Class F or equivalent (high heat tolerance)
• Housing Material: High-strength metal casing with insulation coating
• Operational Temperature: –10°C to 80°C
• Ignition Cable Compatibility: Standard HV silicone cables
• Mounting Type: Universal plate/slot mounting
• Application Compatibility: Gas burners, industrial boilers, furnaces, ovens, thermal equipment

Applications

• Industrial gas burners in commercial kitchens
• Oil & gas-fired boilers for manufacturing plants
• Industrial furnaces and kilns
• Heat-treatment machinery
• Steam and hot-water boilers
• Commercial burner ignition systems
• Retrofit upgrades for outdated ignition transformers

Benefits

• High spark reliability reduces burner ignition failure
• Long lifespan even under heavy-duty use
• Improved energy efficiency reduces operating cost
• Designed for harsh environments (heat, humidity, vibration)
• Ensures burner safety with consistent ignition voltage
• Stable performance across fluctuating power supply
• Ideal for 24/7 industrial operations
