1390 150W CO₂ Laser Cutting & Engraving Machine | Ultra-Precision Camera Tracking Industrial Laser Cutter for Fabric, Leather, Acrylic, Wood & High-Speed Production”

Product Description

Overview

The 1390 150W CO₂ Laser Cutting & Engraving Machine is engineered for industrial-grade performance, delivering ultra-precise cutting, high-speed production, and advanced camera-tracking accuracy for modern manufacturing environments. Built for continuous operation, this machine offers unmatched stability, superior cutting quality, and exceptional versatility across fabric, leather, acrylic, MDF, plywood, rubber, EVA, paperboard, and soft plastics.

Equipped with an advanced HD camera positioning system, the machine ensures pinpoint accuracy for intricate engraving, repetitive production tasks, and complex shape recognition. Whether used in garments, leather goods, signage, packaging, or craft industries, this 1390 model delivers efficiency, speed, and consistent output for maximum business productivity.

With a powerful 150W CO₂ laser tube, auto-focusing, digital control, and a large 1300 × 900 mm working area, it is designed for companies that demand stable, fast, and clean cutting without compromise.

This machine is optimized for high-volume production lines, small manufacturing units, and commercial industries needing professional-grade cutting and engraving performance.

──────────────────────────────────

Key Features

Ultra-Precision Camera Tracking System

• High-definition camera ensures accurate alignment and positioning
• Ideal for printed materials, contour cutting & detailed engraving
• Reduces errors and maximizes consistency in mass production

High-Power 150W CO₂ Laser Tube

• Delivers clean, fast, and sharp cutting across thicker materials
• Supports long-hour continuous operation
• Stable beam quality ensures smooth edges without burning

Large 1300 × 900 mm Working Area

• Supports large sheets of material
• Perfect for garment markers, wood panels, leather sheets & signage

High-Speed Motion Control System

• Industrial-grade guide rails deliver smooth movement
• Rapid acceleration for batch manufacturing
• Superior accuracy for both micro-engraving and high-speed cutting

Auto-Focus & Smart Control Panel

• Automatically adjusts focal height
• Saves time and improves cutting reliability
• Intuitive controls allow easy file loading & process management

Full Material Compatibility

Optimized for:
• Fabric & textile
• Leather & synthetic leather
• Acrylic & PMMA
• MDF, plywood & soft woods
• Paperboard & packaging
• Rubber, EVA foam & soft plastics

Industrial Metal Frame Construction

• Heavy-duty body reduces vibration during high-speed movement
• Ensures long-term reliability and precision

Advanced Exhaust & Air Assist System

• Removes smoke instantly for clean cuts
• Air assist minimizes burn marks
• Improves engraving clarity & edge quality

──────────────────────────────────

Technical Specifications

Model: 1390 CO₂ Laser Cutting & Engraving Machine
Laser Power: 150W CO₂ sealed glass tube
Working Area: 1300 × 900 mm
Laser Type: CO₂ Gas Laser (10.6 μm wavelength)
Positioning System: HD Camera Tracking / Vision Alignment
Cutting Speed: Up to 600 mm/s
Engraving Speed: Up to 1,000 mm/s
Accuracy: ±0.02 mm
Focusing System: Auto-Focus
Drive System: Stepper or Servo Motor (depending on configuration)
Control System: DSP Digital Controller
Cooling: Industrial Chiller (recommended CW-5200 or higher)
Software Compatibility: RDWorks, LightBurn & industry-standard formats
Supported File Types: AI, DXF, JPG, PNG, PLT, BMP, PDF
Power Supply: AC 220V ± 10%, 50/60Hz
Machine Body: Industrial heavy-duty welded steel frame
Connectivity: USB, LAN, U-disk offline
Exhaust System: Dual exhaust fan with air-assist pump
